Racks
Falcon Series: General Electronics Racks for AV & Telecom applications. Racks are manufactured from CRCA sheet, punched, formed, welded, and powder-coated according to the highest quality standards under a stringent ISO 9001:2015, ISO 14001:2015, and ISO 45001:2018 Manufacturing & Quality Management System to ensure the highest quality product. The standard rack configuration includes a welded frame integrated with side panels and a vented top cover with fan mounting provision, a front transparent toughened glass door with a lock and key, a back metal door with a lock and key, and freestanding on the floor with four caster wheels (two with brakes and two without brakes).
Accessories included in Falcon Series Racks :
- PDU Power Strips
- Units
- Shelves
- Fan Modules
- Rack Ground Kit
Features
- Conforms to relevant ISO Standards.
- Adjustable mounting depth.
- Four adjustable, 19-inch verticals with punched 10 mm square holes and a universal 12.7mm-15.875mm-15.875mm alternating hole pattern offer greater mounting flexibility and maximize usable mounting space.
- Universal 44.45 MM Pitch Holes for DIN Standard Racks.
- State-of-the-art manufacturing methods provide the best product quality and fastest delivery in the industry.
- 100% assured compatibility with all equipment conforming to DIN 41494 (General industrial standard for equipment).
- Powder-coated finish with a seven-tank pretreatment process meeting ASTM standards.
- Grounding & Bonding Options.
- Fan module mount provision on top cover.
| Technical Particulars | |
|---|---|
| Basic Frame | CRCA Steel |
| Construction | Welded |
| Top & Bottom Cover | Welded to Frame with Cable entry exit cut outs |
| Front Door | Lockable Toughened Glass Door |
| Rear Door | Lockable Steel Door |
| 19" Mounting Angle | Formed Steel |
| Std. Equipment Mounting | DIN Std. 10mm Sq. Slots |
| Standard Finish | Powder coated |
| Standard Colour | Grey & Off White OR Black |
| Standard Mounting | Caster wheels (2 with Brake & 2 without Brake) |
| Rack Standard | Conforms to DIN 41494 or equivalent standard |
| Static Load | 150Kg |
| Dimensions Matrix | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Falcon Series | H | h | W | w | w1 | D | d | d1 | Caster |
| 6UX600x600 | 464 | 6U | 600 | 19" | 451 | 600 | 560 | 445 | 85 |
| 9UX600x600 | 597 | 9U | 600 | 19" | 451 | 600 | 560 | 445 | 85 |
| 12UX600x600 | 730 | 12U | 600 | 19" | 451 | 600 | 560 | 445 | 85 |
| 15UX600x600 | 864 | 15U | 600 | 19" | 451 | 600 | 560 | 445 | 85 |
| 17UX600x600 | 952 | 17U | 600 | 19" | 451 | 600 | 560 | 445 | 85 |
| 24UX600x600 | 1264 | 22U | 600 | 19" | 451 | 600 | 560 | 445 | 85 |
| 27UX600x600 | 1397 | 27U | 600 | 19" | 451 | 600 | 560 | 445 | 85 |
| 32UX600x600 | 2063 | 32U | 600 | 19" | 451 | 600 | 560 | 445 | 85 |
| Abbreviations | |||
| Overall Height | H | Usable width Between Front MTG. Angles Overall | w1 |
| Usable Height | h | Depth | D |
| Overall width | W | Usable Depth | d |
| Usable width | w | Usable Depth From Front & Rare Mounting Angle | d1 |
Note:
- It is recommended to distribute the Load along with the U space in the Rack.
- In the Case of Wall mount racks caster will not be a part of the Rack.
- Other models can be manufactured on request.
- Dimensions are in MM.
